High-Performance PA Hose | Durable, Chemical-Resistant, and Customizable for Global Industries
Key Features & Advantages
PA Hose combines the strengths of PA6 and PA12 materials to deliver:
● Chemical Resistance: Resists corrosion from acids, bases, fuels, solvents, and industrial liquids, ensuring stability in aggressive chemical environments.
● Wear Resistance: Smooth inner surface with low permeability and flow resistance minimizes abrasion and prevents rust or scale buildup.
● Electrical Insulation: Extremely low electrical conductivity allows it to function as an effective insulator, suitable for electrical systems or sensitive environments.
● Long Service Life: Engineered for decades of use due to resistance to aging, fatigue, and environmental degradation.
● Temperature Stability: Maintains performance across -40°C to +100°C, with PA12 optionally extending to +140°C for short-term use.
● Customizable Connections: Compatible with insert (carded), bamboo-jointed, crimped, and quick-connect fittings, enabling seamless integration into hydraulic and pneumatic systems.
● Color-Coded Identification: Available in multiple colors (e.g., black, white, red, blue) to simplify pipeline labeling and maintenance in complex setups.
Applications
Our PA Hose is widely used in:
● Automotive Systems: Brake lines, power steering systems, and fuel delivery in cars, trucks, and heavy vehicles.
● Engineering & Heavy Machinery: Hydraulic and pneumatic systems in forklifts, excavators, cranes, and construction equipment, where durability and chemical resistance are critical.
● Industrial Fluid Transfer: Conveying compressed air, water, fuel oil, chemical solvents, and liquid food (e.g., dairy, juices) in factories and food-processing plants.
● Marine & Special Environments: Hydraulic control systems in ships and equipment exposed to high moisture or corrosive conditions.
Technical Specifications
|
Parameter |
Specification |
Notes |
| Fluid Compatibility | Air, water, fuel oil, solvents, industrial liquids, liquid food | Customizable for specialized fluids |
| Burst Pressure (20°C) | Up to 60 bar | Ensures safety in high-pressure systems |
| Maximum Operating Pressure | Up to 45 kgf/cm²(standard grade) | Customized pressure options available |
| Operating Temperature Range | -40°C to +100°C(expandable to +140°C short-term for PA12) | Suitable for extreme environments |
| Connection Types | Insert (carded), bamboo-jointed, crimped, quick-connect | Flexible to integrate with diverse fittings |
| Color Options | Customizable (e.g., black, white, red, blue) | Enhances workflow efficiency and identification |
PA6 vs.PA12 Hose: Key Differences
While both PA6 and PA12 hoses share core advantages (chemical resistance, wear resistance, and long service life), their material properties make them suited for different priorities:
|
Feature |
PA6 Hose |
PA12 Hose |
| Material Origin | Standard-grade PA6 | High-quality imported PA12 (e.g., Japanese-grade) |
| Flexibility | Moderate flexibility | Exceptionally soft and pliable, ideal for tight bends |
| Temperature Range | -40°C to +100°C | -40°C to +100°C (expandable to +140°C short-term) |
| Anti-Twist Performance | Standard resistance | Enhanced resistance to torsional stress (anti-twist) |
| UV Resistance | Not inherently UV-resistant | Optional UV treatment for outdoor durability |
| Cost-Effectiveness | More economical for heavy-duty applications | Premium choice for flexibility and chemical stability |
Why Partner With Us?
● Proven Durability: Engineered to withstand mechanical stress, corrosion, and aging, reducing maintenance and replacement costs over decades of use.
● Seamless Integration: Supports insert (carded), bamboo-jointed, crimped, and quick-connect fittingsfor efficient system assembly.
● Tailored Solutions: Available in PA6(robust, cost-effective) and PA12(flexible, UV-resistant) grades to match your specific needs—whether hardness, flexibility, or chemical resistance is critical.
● Custom Color Options: Enhance workflow efficiency with color-coded hoses for easy identification in complex setups.
Contact Us
For samples, technical data sheets, or customized solutions, reach out to our team.We specialize in optimizing PA Hose (PA6 & PA12) for your unique application needs.
Note: Specifications and grades can be adjusted to meet project-specific requirements.Share your details for a tailored proposal.
